Part No. & Part Description
Price & Qty.
Part No. &
Part Description
SENSOR, A/C Electric Temperature and Motor Control
13587668SENSOR, A/C REFRIGERANT PRESSURE(PART OF 26)(REFERENCE TO GLOBAL CONNECT SERVICE INFORMATION FOR CONNECT INFORMATION)(W/O CIRCUIT)
13587668SENSOR, A/C REFRIGERANT PRESSURE(PART OF 27)(REFERENCE TO GLOBAL CONNECT SERVICE INFORMATION FOR CONNECT INFORMATION)(W/O CIRCUIT)
13587668SENSOR, A/C REFRIGERANT PRESSURE(PART OF 24)(REFERENCE TO GLOBAL CONNECT SERVICE INFORMATION FOR CONNECT INFORMATION)(W/O CIRCUIT)
SEAL, A/C Refrigerant Lines
13579648SEAL, A/C COMPRESSOR & CONDENSER HOSE(SLIMLINE WASHER,1/2")(MULTI-SIDED))
- Fitting Vehicle Options: KD(VB6)
13579648SEAL, A/C EVAPORATOR TUBE(PART OF 26)(SLIMLINE WASHER,1/2")(MULTI-SIDED))
- Fitting Vehicle Options: K
- Require Quantity: 02
- Package Quantity: 1
13579648SEAL, A/C COMPRESSOR & CONDENSER HOSE(19 MM OUTSIDE DIAMETER X 11 MM INSIDE DIAMETER)(1/2 INCH DIAMETER)(SLIMLINE WASHER,1/2")(MULTI-SIDED))
- Fitting Vehicle Options: KD(VB6)
13579648SEAL, A/C COMPRESSOR & CONDENSER HOSE(19 MM OUTSIDE DIAMETER X 11 MM INSIDE DIAMETER)(1/2 INCH DIAMETER)(SLIMLINE WASHER,1/2")(MULTI-SIDED))
- Fitting Vehicle Options: KD(VB6)
- Require Quantity: 02
- Package Quantity: 1
13579648SEAL, A/C EVAPORATOR TUBE(19 MM OUTSIDE DIAMETER X 11 MM INSIDE DIAMETER)(1/2 INCH DIAMETER)(PART OF 24)(SLIMLINE WASHER,1/2")(MULTI-SIDED))
- Fitting Vehicle Options: K
- Require Quantity: 02
- Package Quantity: 1
52477087SEAL, A/C EVAPORATOR TUBE(16 MM OUTSIDE DIAMETER X 8 MM INSIDE DIAMETER)(METAL/RUBBER O-RING)(PART OF 1)(16MM OUTSIDE DIAMETER X 8MM INSIDE DIAMETER)(METAL/RUBBER)(R-134A)
- Fitting Vehicle Options: K
- Replaced By: 13579649
52474375SEAL, A/C COMPRESSOR & CONDENSER HOSE(25 MM OUTSIDE DIAMETER X 17 MM INSIDE DIAMETER)(3/4 INCH DIAMETER)(PART OF 13)(25MM OUTSIDE DIAMETER X 17MM INSIDE DIAMETER)(METAL/RUBBER)
- Fitting Vehicle Options: K(VB6)
- Require Quantity: 02
- Package Quantity: 1
89019245SEAL, A/C COMPRESSOR & CONDENSER HOSE(PART OF 13)(5/8")(CONTAINS 2 SEALS/METAL/RUBBER O-RINGS)
- Fitting Vehicle Options: K
89019245SEAL, A/C COMPRESSOR & CONDENSER HOSE(23.5 OUTSIDE DIAMETER X 15.5MM INSIDE DIAMETER)(PART OF 1)(5/8")(CONTAINS 2 SEALS/METAL/RUBBER O-RINGS)
- Fitting Vehicle Options: K
89019245SEAL, A/C COMPRESSOR & CONDENSER HOSE(23.5 OUTSIDE DIAMETER X 15.5MM INSIDE DIAMETER)(PART OF 1,12)(5/8")(CONTAINS 2 SEALS/METAL/RUBBER O-RINGS)
- Fitting Vehicle Options: K
22872400SEAL, A/C COMPRESSOR & CONDENSER HOSE(PART OF 1)(5/8")(9.214)(FOR A/C EVAPORATOR HOSE)
- Fitting Vehicle Options: K
22872400SEAL, A/C COMPRESSOR & CONDENSER HOSE(PART OF 1,12)(5/8")(9.214)(FOR A/C EVAPORATOR HOSE)
- Fitting Vehicle Options: K
3041827CORE, A/C Compressor, CORE,A/C REFRIGERANT SERVICE VALVE(INCLUDES SPRING, WITHOUT O-RING)(13/64-36 THREAD)(PART OF 27)(W/O FITTING)(W/O SEAL)
25769584RADIATOR, (SEE GROUP 01.000 "RADIATOR ASM" FOR DETAILED ILLUSTRATED VIEW)(INCLUDES 15)(35MM)(CODE ACR)
- Fitting Vehicle Options: K(EXC B9Q,V4U,W20)
25769585RADIATOR, (SEE GROUP 01.000 "RADIATOR ASM" FOR DETAILED ILLUSTRATED VIEW)(INCLUDES 17)
- Fitting Vehicle Options: K(B9Q,V4U,W20,V08)
25769585RADIATOR, (SEE GROUP 01.000 "RADIATOR ASM" FOR DETAILED ILLUSTRATED VIEW)(INCLUDES 18)
- Fitting Vehicle Options: K(B9Q,V4U,W20,V08)
11561065STUD, A/C COMPRESSOR HOSE(PART OF 1)(GMW3200)(M8X1.25X13.5/M8X1.25X27)(9.190)
- Fitting Vehicle Options: K
11561065STUD, A/C COMPRESSOR HOSE(PART OF 1)(GMW3200)(M8X1.25X13.5/M8X1.25X27)(9.190)
- Fitting Vehicle Options: K
- Require Quantity: 02
- Package Quantity: 1
89018617STUD, A/C COMPRESSOR HOSE(PART OF 1)(M8X1.25X45,M8X1.25X14)
- Fitting Vehicle Options: KD(69), K
15858581HOSE, A/C COMPRESSOR(SUCTION)(USE ON CARS BUILT ON 03/20/06 OR LATER. FOR 1ST DESIGN SEE 15260240.)(INCLUDES 12)
- Fitting Vehicle Options: K(VB6)
22752061HOSE, A/C COMPRESSOR & CONDENSER(INCLUDES 15,23-25)
- Fitting Vehicle Options: K(EXC VB6)
22752061HOSE, A/C COMPRESSOR & CONDENSER(INCLUDES 14,21-23,28)
- Fitting Vehicle Options: K(EXC VB6)
15260240HOSE, A/C COMPRESSOR(SUCTION)(USE ON CARS BUILT PRIOR TO 03/20/06. FOR 2ND DESIGN SEE 15858581.)(INCLUDES 12)
- Fitting Vehicle Options: K(VB6)
15858582HOSE, A/C COMPRESSOR(DISCHARGE)(USE ON CARS BUILT ON 1GEEH96956U550585 OR LATER FOR 1ST DESIGN SEE 15260241.)(INCLUDES 16,24-26)
- Fitting Vehicle Options: K(VB6)
19259540HOSE, A/C COMPRESSOR(DISCHARGE)(USE ON CARS BUILT PRIOR TO 1GEEH96956U550585 FOR 2ND DESIGN SEE 15858582.)(INCLUDES 16,24-26)
- Fitting Vehicle Options: K(VB6)
25994170HOSE, A/C COMPRESSOR(INCLUDES 12)
- Fitting Vehicle Options: K
25994170HOSE, A/C COMPRESSOR(INCLUDES 5)
- Fitting Vehicle Options: K(EXC VB6)
HOSE, A/C Refrigerant (Metal and Rubber Sections)
15880944HOSE, A/C EVAPORATOR(INCLUDES 2-6,8-10,25-27)
- Fitting Vehicle Options: K(EXC V4U)
15880982HOSE, A/C EVAPORATOR(INCLUDES 2-6,8-10,27,28)
- Fitting Vehicle Options: K(V4U)
15880982HOSE, A/C EVAPORATOR(INCLUDES 2-6,8-10,29,30)
- Fitting Vehicle Options: K(V4U)
21999685CLIP, A/C EVAPORATOR TUBE(PART OF 1)(HOLDS TWO TUBES TOGETHER)
21999686CLIP, A/C EVAPORATOR TUBE(PART OF 1,10)(HOLDS ONE TUBE TO A BRACKET)
88957401CAP, A/C REFRIGERANT LOW PRESSURE SERVICE VALVE(PART OF 1)(NON-TETHERED)
- Require Quantity: 02
- Package Quantity: 1
88957402CAP, A/C REFRIGERANT HIGH PRESSURE SERVICE VALVE(PART OF 1)(NON-TETHERED)
- Require Quantity: 02
- Package Quantity: 1
BRACKET, A/C Refrigerant (Metal and Rubber Sections)
15881002BRACKET, A/C EVAPORATOR HOSE(SUCTION/LIQUID ASSEMBLY)(PART OF 1)(INCLUDES 8,9)
- Fitting Vehicle Options: KD(69)
15881002BRACKET, A/C EVAPORATOR HOSE(PART OF 1)(INCLUDES 8,9)(SUCTION/LIQUID ASSEMBLY)
- Fitting Vehicle Options: KD
FILTER, A/C Refrigerant Lines
Standard Parts
11514596NUT, HEX FLANGED HEAD,M8X1.25,17.9 OUTSIDE DIAMETER,738 THICK,13MM HEXAGON,10, PHOSPHATE ZINC ORGANIC - FLAKE(A/C COMPRESSOR HOSE)(8.915)
- Require Quantity: 02
- Package Quantity: 1
11514596NUT, HEX FLANGED HEAD,M8X1.25,17.9 OUTSIDE DIAMETER,738 THICK,13MM HEXAGON,10, PHOSPHATE ZINC ORGANIC - FLAKE(A/C EVAPORATOR HOSE)(8.915)
- Require Quantity: 03
- Package Quantity: 1
11514596NUT, HEX FLANGED HEAD,M8X1.25,17.9 OUTSIDE DIAMETER,738 THICK,13MM HEXAGON,10, PHOSPHATE ZINC ORGANIC - FLAKE(A/C EVAPORATOR HOSE)(8.915)
- Require Quantity: 04
- Package Quantity: 1
11609411NUT, HEXAGON W/CONICAL WASHER,M6X1,5.7 THICK,16 OUTSIDE DIAMETER,9,GMW3200(A/C EVAPORATOR HOSE)
11570097NUT, U-TYPE,M6X1, 21.4X15, 11.7 C/E, SAE 1050 STEEL,GMW3359.(PART OF 18)
- Require Quantity: 04
- Package Quantity: 1
11570097NUT, U-TYPE,M6X1, 21.4X15, 11.7 C/E, SAE 1050 STEEL,GMW3359.(PART OF 19)
- Require Quantity: 04
- Package Quantity: 1
11570097NUT, U-TYPE,M6X1, 21.4X15, 11.7 C/E, SAE 1050 STEEL,GMW3359.(PART OF 16)
- Require Quantity: 04
- Package Quantity: 1
11570136BOLT, HEXAGON HEAD,W/CONICAL SPRING WASHER,M6X1X23,14 THREAD,17 O.D.,8.8,GMW3359(RADIATOR)
- Require Quantity: 02
- Package Quantity: 1
- Replaced By: 11548922
19188397O-RING, 7.65MM INSIDE DIAMETER, 1.78 MM THICK,NEOPRENE(PART OF 27)
Genuine GM Parts, the Right Choice
GMPartsGiant.com offers the wholesale prices for genuine 2006
Cadillac DTS parts. Parts like A/C Refrigeration System are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 8 Cyl 4.6L. Model Code: 4 DOOR, FUNERAL COACH, LIMOUSINE.
3041827
$3.83 $2.431
