Transfer Case Components-Front fit your 2004 GMC Safari AWD

Currently shopping for

2004 GMC Safari AWD

Change Vehicle

Vehicle Options

6 Cyl 4.3L MFI, 90 DEG; 4-Speed Automatic Transmission, 4L60-E, Electronic

Vehicle Options

6 Cyl 4.3L MFI, 90 DEG; 4-Speed Automatic Transmission, 4L60-E, Electronic

Categories Close X

Currently selected

Transfer Case

Other Categories

Body Mounting, Air Conditioning, Audio/Entertainment

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cab And Body Structure, Mirrors, Doors, Trim, Seat Belts, Wipers

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers

Front Axle, Front Suspension, Steering

Front End Sheet Metal, Heater

Fuel System, Exhaust, Emission System

Maintenance Parts, Fluids, Capacities, Electrical Connectors

Rear Body Structure, Moldings & Trim, Cargo Stowage

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Automatic

Parts Questions

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

PIN, Transfer Case
89059638
PIN, TRANSFER CASE FOUR WHEEL DRIVE CLUTCH LEVER PIVOT(INCLUDES 34,35)(INCLUDES THE WASHER & SEALS)
Require Quantity: 02
Package Quantity: 1
$43.46 $27.63
14037948
PIN, TRANSFER CASE HALF LOCATING(TYPE 241C/243C)(DOWEL)
- Require Quantity: 02
- Package Quantity: 1

19302667
SENSOR, Computer Control Sensors, SENSOR,VEHICLE SPEED(SCREW IN WITH O-RING)(INCLUDES 30)(IF NEEDING MATING CONNECTOR USE 88987993)(THREADED STYLE)(USE TOGETHER WITH CONNECT 15306187 W/LEADS)
- Require Quantity: 03
- Package Quantity: 1
$84.19 $44.63
1
Add To Cart

19302667
SENSOR, Speedometer Drive, SENSOR,VEHICLE SPEED(SCREW IN WITH O-RING)(INCLUDES 30)(IF NEEDING MATING CONNECTOR USE 88987993)(THREADED STYLE)(3.682)(USE TOGETHER WITH CONNECT 15306187 W/LEADS)
- Require Quantity: 03
- Package Quantity: 1
$84.19 $44.63
1
Add To Cart

12547642
BOLT, Transfer Case Internal Shift Control, BOLT,TRANSFER CASE SHIFT DETENT SPRING(5/8-18 X 1/2)(ALUMINUM)(4.510)

BEARING, Transfer Case

12547464
BEARING, TRANSFER CASE SHIFT DETENT LEVER(INCLUDES SEAL)(4.570)
$28.64 $18.20
1
Add To Cart
89059659
BEARING, TRANSFER CASE INPUT SHAFT
$128.57 $46.78
1
Add To Cart
19177499
BEARING, TRANSFER CASE FRONT OUTPUT SHAFT FRONT(TYPE 241C/243C)(PART OF 29)

SEAL, Transfer Case

12547466
SEAL, TRANSFER CASE INPUT SHAFT
$82.52 $49.85
1
Add To Cart
12544077
SEAL, TRANSFER CASE(SHAFT TO YOKE)
$13.05
1
Add To Cart
12547478
SEAL, TRANSFER CASE FRONT OUTPUT SHAFT(SHAFT TO CASE)
$27.91 $13.84
1
Add To Cart
14071849
SEAL, TRANSFER CASE SHIFT DETENT PLUNGER PLUG(O RING)(.648 O.D.)(4.563)

RING, Transfer Case

682653
RING, TRANSFER CASE INPUT GEAR BEARING OUTER RETAINER(SNAP)(TYPE 241C/243C)(PART OF 29)(1.82" FREE INSIDE DIAMETER X .094" THICK)(4.412)
$2.14 $1.36
10
Add To Cart
15662234
RING, TRANSFER CASE SHIFT DETENT LEVER RETAINER(STEEL)(C-RING)
$12.21 $7.76
1
Add To Cart
12547465
RING, TRANSFER CASE INPUT GEAR BEARING RETAINER(PART OF 29)(3.36MM)(.064MM THICK)(INNER)(4.525)
$12.60
1
Add To Cart
15547377
RING, TRANSFER CASE FRONT OUTPUT SHAFT REAR BEARING RETAINER(PART OF 29)

15547432
SCREEN, Transfer Case, SCREEN,TRANSFER CASE OIL PUMP(TYPE 241C/243C)(PART OF 13)

89059654
VENT, Transfer Case, VENT,TRANSFER CASE(ALUMINUM VENT)
$21.84 $13.21
1
Add To Cart

LEVER, Transfer Case

12474067
LEVER, TRANSFER CASE FOUR WHEEL DRIVE CLUTCH
12470550
LEVER, TRANSFER CASE SHIFT DETENT(INCLUDES LEVER & SHAFT)

12471607
MAGNET, Transfer Case, MAGNET,TRANSFER CASE CHIP COLLECTOR(4.105)
$13.57 $8.20
1
Add To Cart

12474041
ACTUATOR, Transfer Case Shift Control, ACTUATOR,TRANSFER CASE FOUR WHEEL DRIVE(INCLUDES ENCODER MOTOR)
$592.04 $334.18
1
Add To Cart

12547462
CASE, Transfer Case, CASE,TRANSFER(FRONT HALF)
$642.39 $473.51
1
Add To Cart

25624810
BOLT, Transfer Case Shift Control, BOLT,TRANSFER CASE TWO/FOUR WHEEL DRIVE ACTUATOR(M10X1.5X40)(HEX FLANGED HEAD)(4.085)
- Require Quantity: 03
- Package Quantity: 1
$4.50 $2.87
1
Add To Cart

12474072
PLUNGER, Transfer Case Internal Shift Control, PLUNGER,TRANSFER CASE SHIFT DETENT

12547647
STUD, Transfer Case, STUD,TRANSFER CASE

15633557
SPRING, Transfer Case Internal Shift Control, SPRING,TRANSFER CASE SHIFT DETENT

88891184
INSULATOR, Transfer Case Shift Control, INSULATOR,TRANSFER CASE FOUR WHEEL DRIVE ACTUATOR

88962328
PIPE, Transfer Case, PIPE,TRANSFER CASE OIL PUMP SUCTION(INCLUDES 37)(INCLUDES OIL PUMP SCREEN)

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2004 GMC Safari AWD parts. Parts like Transfer Case Components-Front are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 4.3L. Model Code: VAN SAFARI.
