Part No. & Part Description
Price
Part No. &
Part Description
16643104CLIP, REAR DOOR LOCK ROD(PART OF 24)(YELLOW)(PLASTIC)(8.083)
- Fitting Vehicle Options:
G1,2,3(05-06)
16640343CLIP, REAR DOOR LOCK ROD(PART OF 24)(YELLOW)(W/ROD WITH (2) 90 DEGREE BENDS)(THREADED)(10.527)
- Fitting Vehicle Options:
G1,2,3(05-06)
16600277CLIP, REAR DOOR LOCK ROD(PART OF 24)(SPRING CLIP)(10.550)
- Fitting Vehicle Options:
G1,2,3
11561015BOLT, REAR DOOR LATCH(UPPER)(8.913)
- Require Quantity:
02
- Package Quantity:
1
11609341BOLT, REAR DOOR LATCH(LOWER)(M6X1X19)(USE NUT 11610510)(8.903)
- Require Quantity:
04
- Package Quantity:
1
GASKET, Door Lock Cylinder
12547752GASKET, REAR DOOR LOCK CYL(RUBBER)(STRATTEC)
- Require Quantity:
02
- Package Quantity:
1
15994457HINGE KIT, REAR DOOR LOWER(INCLUDE 4)(INCLUDES DOOR & BODY SIDE)
- Location:
Driver Side
- Fitting Vehicle Options:
G1,2,3(05-06)
15994451HINGE KIT, REAR DOOR UPPER(INCLUDE 4)(INCLUDES DOOR & BODY SIDE)
- Location:
Driver Side
- Fitting Vehicle Options:
G1,2,3
15994452HINGE KIT, REAR DOOR UPPER(INCLUDE 4)(INCLUDES DOOR & BODY SIDE)
- Location:
Passenger Side
- Fitting Vehicle Options:
G1,2,3
15994458HINGE KIT, REAR DOOR LOWER(INCLUDE 4)(INCLUDES DOOR & BODY SIDE)
- Location:
Passenger Side
- Fitting Vehicle Options:
G1,2,3(05-06)
STRIKER, Door Lock Striker
HANDLE, Door Lock Remote Control Inside
11589019BOLT, Door Lock Striker, BOLT,REAR DOOR LOCK STRIKER(SCREW,FLAT,CSK,M8X1.25X35,28 THREAD,15.4 OUTSIDE DIAMETER,9.8,3044GMW,TORX, SILVER)(8.908)
- Require Quantity:
02
- Package Quantity:
1
15101589PLUG, Rear, PLUG,REAR DOOR DRAIN HOLE(FITS HOLE SIZE 22 MM)(W/SPRING CLIP)(17.185)
- Require Quantity:
02
- Package Quantity:
1
88981041LOCK, REAR DOOR(LESS PLATE, LEVERS, HOUSING, BUMPERS, HARDWARE)
- Fitting Vehicle Options:
G1,2,3(05-06)(EXC 6L9)
22834664LOCK, REAR DOOR(INCLUDES PLATE,LEVER'S,HOUSING,BUMPER'S,HARDWARE)(DOOR AJAR SWITCH BUILT INTO LOCK)
22834666LOCK, REAR DOOR(INCLUDES DOOR AJAR SWITCH)(INCLDS LOCK,LEVERS,HOUSINGS,BUMPERS,HARDWARE)
- Fitting Vehicle Options:
G1,2,3(05-06)(AU3)
- Replaced By:
86593006
15111459LOCK, REAR DOOR
- Fitting Vehicle Options:
G1,2,3(05-06)(6L9)
LABEL, Emissions and Cautions
10442881LABEL, CHILD SECURITY LOCK OPERATING INSTRUCTION(INTERNATIONAL)
- Fitting Vehicle Options:
G1,2,3(05-06)(YA2)
10444933LABEL, CHILD SECURITY LOCK INFORMATION(BI-LINGUAL)(ON WINDOW)(TO BLACK ENAMEL PLACED IN THE INCOMP VEHICLE DOCUMENTATION. ENVELOPE 686186)
- Fitting Vehicle Options:
G1,2,3(05-06)
25729624LABEL, REAR DOOR SEALING BODY BUILDER NOTE WARNING
- Fitting Vehicle Options:
G1,2,3(05)(YF7,YF9)
- Require Quantity:
02
- Package Quantity:
1
25735934LABEL, CHILD SECURITY LOCK OPERATING INSTRUCTION(PICTORIAL)
- Location:
Passenger Side
- Fitting Vehicle Options:
G1,2,3(05-06)(E24)
11571164NUT, Door, NUT,REAR DOOR WEDGE(DOOR SIDE)(UPPER LH/RH & LOWER RH)(16.545)
- Require Quantity:
06
- Package Quantity:
1
12549265DOOR, REAR(W/HINGES)
- Location:
Driver Side
- Fitting Vehicle Options:
G1,2,3(05)(EXC A12,A18)
12549267DOOR, REAR(W/HINGES)
- Location:
Driver Side
- Fitting Vehicle Options:
G1,2,3(06)
- Replaced By:
22861239
12549267DOOR, REAR(W/HINGES)(WHEN USING ON VEHS W/A18,SWING OUT WINDOW,MAY NEED TO DRILL HOLES FOR HINGES AND LATCH)
- Location:
Driver Side
- Fitting Vehicle Options:
G1,2,3(05)(A12,A18)
- Replaced By:
22861239
22939491DOOR, REAR(W/HINGES)
- Location:
Passenger Side
- Fitting Vehicle Options:
G1,2,3(05)(EXC A12,A18)
22939492DOOR, REAR(W/HINGES)(WHEN USING ON VEHS W/A18,SWING OUT WINDOW,MAY NEED TO DRILL HOLES FOR HINGES AND LATCH)
- Location:
Passenger Side
- Fitting Vehicle Options:
G1,2,3(06)(A12,A18), G1,2,3(05)(A12,A18)
15743840WEDGE, REAR DOOR (BODY SIDE)(UPPER)
- Require Quantity:
02
- Package Quantity:
1
15845695WEDGE, REAR DOOR (BODY SIDE)(LOWER)
- Require Quantity:
02
- Package Quantity:
1
15845694WEDGE, Door, WEDGE,REAR DOOR (DOOR SIDE)(UPPER)(UPPER)
- Require Quantity:
02
- Package Quantity:
1
15960306WEDGE, WEDGE,REAR DOOR (DOOR SIDE)(LOWER)
- Require Quantity:
02
- Package Quantity:
1
Standard Parts
11609411NUT, HEXAGON W/CONICAL WASHER,M6X1,5.7 THICK,16 OUTSIDE DIAMETER,9,GMW3200(REAR DOOR OUTSIDE HANDLE)
11609989BOLT, HEXAGON W/FLAT WASHER,M6X1X25,15 THREAD,17 OUTSIDE DIAMETER,6202M STEEL,GMW3200,TAPTITE(REAR DOOR WEDGE(DOOR SIDE))
- Require Quantity:
06
- Package Quantity:
4
11609989BOLT, HEXAGON W/FLAT WASHER,M6X1X25,15 THREAD,17 OUTSIDE DIAMETER,6202M STEEL,GMW3200,TAPTITE(REAR DOOR WEDGE(BODY SIDE))
- Require Quantity:
04
- Package Quantity:
4
11609989BOLT, HEXAGON W/FLAT WASHER,M6X1X25,15 THREAD,17 OUTSIDE DIAMETER,6202M STEEL,GMW3200,TAPTITE(REAR DOOR LATCH STRIKER)
- Require Quantity:
02
- Package Quantity:
4
11589407BOLT, HEX WASHER HEAD, M8X1.25X35, 23.5 THREAD, 24 OUTSIDE DIAMETER, 10.9, GMW3359, M-POINT.(PART OF 3,35,41,42)
- Require Quantity:
04
- Package Quantity:
1
11609341SCREW, ROUND WASHER HEAD M6X1X19, 13.55 THREAD,16 OUTSIDE DIAMETER,10.9,GMW4205,W/ADH GM6175M,MATPT(REAR DOOR WEDGE (DOOR SIDE) LH LOWER)
- Require Quantity:
02
- Package Quantity:
1
11609341SCREW, ROUND WASHER HEAD M6X1X19, 13.55 THREAD,16 OUTSIDE DIAMETER,10.9,GMW4205,W/ADH GM6175M,MATPT(REAR DOOR LOCK)
- Require Quantity:
03
- Package Quantity:
1
Genuine GM Parts, the Right Choice
GMPartsGiant.com offers the wholesale prices for genuine 2002
GMC Savana 3500 parts. Parts like Door Hardware/Rear are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 4.3L, 8 Cyl 5.7L, 8 Cyl 6.5L Diesel, 8 Cyl 8.1L. Model Code: 1 TON CARGO SAVANA, 1 TON COMMERCIAL/RECREATIONAL VEHICLE SAVANA, 1 TON PASSENGER.
