Manual Transaxle Gear Shift Fork & Shaft fit your 2002 Chevrolet Prizm

Currently shopping for

2002 Chevrolet Prizm

Change Vehicle

Vehicle Options

4 Cyl 1.8L MFI; Prizm 4 Door

Vehicle Options

4 Cyl 1.8L MFI; Prizm 4 Door

Categories Close X

Currently selected

Transmission - Manual

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Automatic

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

Parts Questions

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

ARM, Transmission Internal Shift

94855593
ARM, 3RD & 4TH SHIFT FORK
$28.67 $23.38
1
Add To Cart
94842991
ARM, 1ST & 2ND SHIFT FORK

94853938
SPRING, Transmission Synchronizer, SPRING,3RD & 4TH GEAR SYN(24.6MM OUTSIDE DIAMETER)(SEAT)(49.9MM LONG)
$4.14 $3.38
1
Add To Cart

94840621
GASKET, Transmission Control Lever, GASKET,SHIFT CONTROL SHAFT COVER(PART OF 18)

94840764
SHAFT, Transmission Internal Shift, SHAFT,SHIFT CONTROL

94840765
PLATE, Transmission Internal Shift, PLATE,SHIFT INTERLOCK

94840768
COVER, Transmission Internal Shift Shaft, COVER,SHIFT CONTROL SHAFT(INCLUDES 15-18)

94840769
BOOT, Transmission Control Lever, BOOT,SHIFT CONTROL SHAFT(PART OF 17)

SEAT, Transmission Shift Shaft Detent

94840773
SEAT, 1ST & 2ND SHIFT SHAFT DETENT SPRING(28.9MM LONG)(9.7MM INSIDE DIAMETER, 10.6MM O.D.)
94840773
SEAT, 5TH SHIFT SHAFT DETENT SPRING(28.9MM LONG)(9.7MM INSIDE DIAMETER, 10.6MM O.D.)
94840773
SEAT, 3RD & 4TH SHIFT SHAFT DETENT SPRING(28.9MM LONG)(9.7MM INSIDE DIAMETER, 10.6MM O.D.)

BALL, Transmission Shift Shaft Detent

94840774
BALL, 1ST & 2ND SHIFT SHAFT DETENT(9.53MM DIAMETER)
94840774
BALL, 5TH SHIFT SHAFT DETENT(9.53MM DIAMETER)

94840774
BALL, Transmission Internal Shift, BALL,3RD & 4TH SHIFT SHAFT DETENT(9.53MM DIAMETER)

94840786
BALL, Transmission Interlock, BALL,REV SHIFT FORK DETENT(6.35MM OUTSIDE DIAMETER)(STEEL)
- Require Quantity: 02
- Package Quantity: 1

BOLT, Transmission Internal Shift Shaft
94842250
BOLT, SHIFT CONTROL SHAFT COVER(M10X1.25X25)(CONTAINS WASHER-17.4MM O.D.)
Require Quantity: 02
Package Quantity: 1
94856602
BOLT, SHIFT CONTROL SHAFT COVER(M10X1.25X25)
- Require Quantity: 02
- Package Quantity: 1

94842646
PIN, Transmission Shift Shaft Detent, PIN,REV INHIBITOR(5.2MM OUTSIDE DIAMETER)(CAM RETAINER)(SLOTTED SPRING)(20MM LONG)

94842647
PIN, Transmission Internal Shift, PIN,3RD & 4TH SHIFT FORK(ARM RETAINER)(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)

94842647
PIN, Transmission Rail End, PIN,CONTROL SELECTOR ARM(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)

PLUG, Transmission Shift Shaft Detent

94842684
PLUG, REV INHIBITOR CAM PINION HOLE(M10X1.25X7.5)(15MM ROUND HEAD, 6MM HEXAGON RECESS)
94842685
PLUG, 1ST & 2ND SHIFT SHAFT DETENT(M12X1.25X8.3)(18MM ROUND HEAD W/6MM HEXAGON)
94842685
PLUG, 3RD & 4TH SHIFT SHAFT DETENT(M12X1.25X8.3)(18MM ROUND HEAD W/6MM HEXAGON)

94842685
PLUG, Transmission Internal Shift, PLUG,5TH SHIFT SHAFT DETENT(M12X1.25X8.3)(18MM ROUND HEAD W/6MM HEXAGON)

94842909
GASKET, Transmission Internal Shift, GASKET,SHIFT INTERLOCK PLATE BOLT(18MM INSIDE DIAMETER, 24MM O.D.)(2.0MM THICK)

94843048
RING, Transmission Synchronizer, RING,3RD & 4TH GEAR SYN SPRING SEAT RETAINER(12MM INSIDE DIAMETER, 23MM OUTSIDE DIAMETER)(1.5MM THICK)

RING, Transmission Internal Shift Shaft
94843437
RING, 1ST & 2ND SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)
Fitting Vehicle Options: S(LV6,MB4)
94843437
RING, 5TH SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)
- Fitting Vehicle Options: S(MB4)
94843437
RING, 3RD & 4TH SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)
- Fitting Vehicle Options: S(LV6,MB4)

94843437
RING, Transmission Internal Shift Fork, RING,REV SHIFT FORK RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)

94843438
RING, Transmission Internal Shift, RING,1ST & 2ND SELECTOR STOP SPRING SEAT RETAINER(15MM INSIDE DIAMETER, 21MM OUTSIDE DIAMETER)(1.5MM THICK)

94846156
BLOCK, Transmission Internal Shift, BLOCK,3RD & 4TH SHIFT

BOLT, Transmission Internal Shift

94846157
BOLT, 3RD & 4TH SHIFT BLOCK(M6X0.75X21)
94846157
BOLT, 1ST & 2ND SHIFT FORK(M6X0.75X21)
94846157
BOLT, 3RD & 4TH SHIFT FORK(M6X0.75X21)
94846157
BOLT, 5TH SHIFT FORK(M6X0.75X21)
94856642
BOLT, REV SHIFT LEVER BRACKET(M8X1.25X18)(INCLUDES WASHER-15MM O.D.)
- Require Quantity: 02
- Package Quantity: 1

94849494
CAM, Transmission Shift Shaft Detent, CAM,REV INHIBITOR(INCLUDES SHAFT)

FORK, Transmission Internal Shift

94851593
FORK, 1ST & 2ND SHIFT
94855909
FORK, REV SHIFT
94859750
FORK, 3RD & 4TH SHIFT
94859751
FORK, 5TH SHIFT

94854092
VENT, Transmission Case, VENT,MANUAL TRANSMISSION(10MM DIAMETER, 27MM LONG)

94854732
SEAL, Transmission Control Lever, SEAL,SHIFT CONTROL SHAFT COVER(PART OF 17)(18MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(8MM HIGH)

94855303
SPRING, Transmission Internal Shift, SPRING,1ST & 2ND SELECTOR STOP(76.4MM LONG)

94855594
ARM, Transmission Control, ARM,CONTROL SELECTOR

94855595
SEAT, Transmission Internal Shift, SEAT,1ST & 2ND SELECTOR STOP SPRING(18MM INSIDE DIAMETER, 34MM OUTSIDE DIAMETER)(14MM HIGH)

94855596
SEAT, Transmission Synchronizer, SEAT,3RD & 4TH GEAR SYN SPRING(15MM INSIDE DIAMETER, 32MM OUTSIDE DIAMETER)(15.5MM HIGH)

94855871
BRACKET, Transmission Rail End, BRACKET,REV SHIFT LEVER(INCLUDES: SHOE & RING)

94859508
BOLT, Transmission Interlock, BOLT,SHIFT INTERLOCK PLATE

SHAFT, Transmission Internal Shift Shaft

94859747
SHAFT, 1ST & 2ND SHIFT
94859748
SHAFT, 3RD & 4TH SHIFT
94859749
SHAFT, 5TH & REV SHIFT

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2002 Chevrolet Prizm parts. Parts like Manual Transaxle Gear Shift Fork & Shaft are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 1.8L. Model Code: 4 DOOR.
