Part No. & Part Description

Price & Qty.

Part No. &
Part Description

19205414
BEARING, Transmission Mainshaft Center/Rear, BEARING,MAIN SHAFT REAR
$86.97 $52.54
1
Add To Cart

SPRING, Transmission Synchronizer
94840730
SPRING, 3RD & 4TH GEAR SYN
Require Quantity: 02
Package Quantity: 1
$22.67 $3.89
1
Add To Cart
94853938
SPRING, 3RD & 4TH GEAR SYN(24.6MM OUTSIDE DIAMETER)(SEAT)(49.9MM LONG)
$4.14 $0.68
1
Add To Cart
94840754
SPRING, 5TH GEAR SYN(58.6MM OUTSIDE DIAMETER)
- Require Quantity: 02
- Package Quantity: 1

BOLT, HEXAGON

94844003
BOLT, HEXAGON(M8X1.25X12) HEADER POINT,W/LOCK WASHER(14.3MM DIAMETER
$1.43
1
Add To Cart
94844007
BOLT, HEXAGON

BEARING, Transmission Clutch Gear
19205640
BEARING, INPUT SHAFT REAR
Fitting Vehicle Options: S(MM5)
94844301
BEARING, INPUT SHAFT FRONT(25MM INSIDE DIAMETER, 43.5MM OUTSIDE DIAMETER)(15MM HIGH)(USED FROM TRANS #608-09236)(1ST DESIGN 94840702)
- Fitting Vehicle Options: S(MM5)(2ND DES)

88974084
RETAINER, Transmission Clutch Gear, RETAINER,INPUT & MAIN SHAFT BEARING

INSERT, Transmission Synchronizer
88974598
INSERT, 5TH GEAR SYN
Require Quantity: 03
Package Quantity: 1
94840728
INSERT, 3RD & 4TH GEAR SYN
- Require Quantity: 03
- Package Quantity: 1

88975052
GEAR, Transmission Countershaft, GEAR,4TH COUNTER

94840434
BALL, Transmission First/Reverse Gear, BALL,1ST GEAR THRUST WASHER LOCATING(4.76MM DIAMETER)

BEARING, Transmission Gear
94840708
BEARING, 1ST GEAR(38MM INSIDE DIAMETER, 44MM OUTSIDE DIAMETER)(26MM HIGH)
Fitting Vehicle Options: S(MM5)
94840710
BEARING, 3RD GEAR(31MM INSIDE DIAMETER, 36MM OUTSIDE DIAMETER)(24.4MM HIGH)
- Fitting Vehicle Options: S(MM5)
94840712
BEARING, 5TH GEAR(24.9MM INSIDE DIAMETER, 29.9MM OUTSIDE DIAMETER)(26.8MM HIGH)
- Fitting Vehicle Options: S(MM5)
94843800
BEARING, 2ND GEAR(32MM INSIDE DIAMETER, 38MM OUTSIDE DIAMETER)(26.5MM HIGH)
- Fitting Vehicle Options: S(MM5)
94844305
BEARING, 4TH GEAR(29MM INSIDE DIAMETER, 34MM OUTSIDE DIAMETER)(24.4MM HIGH)(USED FROM TRANS #608-09236)(HAS A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4T H GEAR SYN RETAINER RING)(1ST DESIGN 94840711)
- Fitting Vehicle Options: S(MM5)(2ND DES)

SPACER,Fourth & Fifth Gear
94840713
SPACER, 5TH GEAR BEARING(25MM INSIDE DIAMETER, 29MM OUTSIDE DIAMETER)(2.5MM THICK)
Fitting Vehicle Options: S(MM5)
94840737
SPACER, 3RD & 4TH COUNTER GEAR(43.5MM OUTSIDE DIAMETER, 28.7MM INSIDE DIAMETER)(24.9MM LONG)
- Fitting Vehicle Options: S(MM5)
94844306
SPACER, 4TH GEAR BEARING(29.2MM INSIDE DIAMETER, 33.1MM OUTSIDE DIAMETER)(2.0MM THICK)(NO COMPARABLE 1ST DESIGN)
- Fitting Vehicle Options: S(MM5)(2ND DES)

94840716
RETAINER, Transmission Rear Bearing & Mainshaft, RETAINER,MAIN SHAFT BEARING

TROUGH, Transmission Case

94840717
TROUGH, MANUAL TRANSMISSION OIL(DIFFERENTIAL HOUSING)
94840721
TROUGH, MANUAL TRANSMISSION OIL(FRONT)(T-SHAPE)
94840722
TROUGH, MANUAL TRANSMISSION OIL(REAR)

HUB, Transmission Synchronizer

94840726
HUB, 3RD & 4TH GEAR SYN
94840750
HUB, 5TH GEAR SYN

RING, Transmission Synchronizer
94840729
RING, 3RD GEAR BLOCKING
Fitting Vehicle Options: S(MM5)
94840729
RING, 4TH GEAR BLOCKING
- Fitting Vehicle Options: S(MM5)
94843441
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE A)(2.25-2.30MM THICK)
- Fitting Vehicle Options: S(MM5)
94843442
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE B)(2.31-2.36MM THICK)
- Fitting Vehicle Options: S(MM5)
94843443
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE C)(2.37-2.42MM THICK)
- Fitting Vehicle Options: S(MM5)
94843444
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE D)(2.43-2.48MM THICK)
- Fitting Vehicle Options: S(MM5)
94843445
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE E)(2.49-2.54MM THICK)
- Fitting Vehicle Options: S(MM5)
94843446
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE F)(2.55-2.560MM THICK)
- Fitting Vehicle Options: S(MM5)
94843447
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE G)(2.61-2.66MM THICK)
- Fitting Vehicle Options: S(MM5)
94843460
RING, 1ST & 2ND GEAR SYN RETAINER(CODE A)(2.50MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94843461
RING, 1ST & 2ND GEAR SYN RETAINER(CODE B)(2.56MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94843462
RING, 1ST & 2ND GEAR SYN RETAINER(CODE C)(2.62MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94843463
RING, 1ST & 2ND GEAR SYN RETAINER(CODE D)(2.68MM THICK)(36.6MM O.D.,29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94843464
RING, 1ST & 2ND GEAR SYN RETAINER(CODE E)(2.74MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94843465
RING, 1ST & 2ND GEAR SYN RETAINER(CODE F)(2.80MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
- Fitting Vehicle Options: S(MM5)
94844307
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 0)(2.30-2.35MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 0)(2.30MM THICK)(USED FROM TRANS #608-09236)(USES A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(1ST DESIGN 94843454)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94844308
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 1)(2.36-2.41MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 1)(2.36MM THICK)(USED FROM TRANS #608-09236)(USES A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RING)(1ST DESIGN 94843455)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94844309
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 2)(2.42-2.47MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 2)(2.42MM THICK)(USED FROM TRANS #608-09236)(USES A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(1ST DESIGN 94843456)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94844310
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 3)(2.482.53MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 3)(2.48MM THICK)(USED FROM TRANS #608-09236)(USES A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(1ST DESIGN 94843457)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94844311
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 4)(2.54MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 4)(2.54MM THICK)(USED FROM TRANS #608-09236)(USED A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(1ST DESIGN 94843458)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94844312
RING, 3RD & 4TH GEAR SYN HUB RETAINER(IDENTIFY: 5)(2.60MM THICK)(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 5)(2.60MM THICK)(USED FROM TRANS #608-09236)(USES A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(1ST DESIGN 94843459)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94851783
RING, 5TH GEAR BLOCKING
- Fitting Vehicle Options: S(MM5)
94851929
RING, 4TH GEAR BLOCKING(USED FROM TRANS #608-09236)(HAS A SPACER BETWEEN 4TH GEAR BEARING & 3RD & 4TH GEAR SYN RETAINER RING)(USE TOGETHER WITH 94851927 GEAR)
- Fitting Vehicle Options: S(MM5)(2ND DES)
94851929
RING, 3RD GEAR BLOCKING(INSIDE OF RING IS GOLD COLOR)(REPAIR-REQUIRED WHEN USING 94851926 3RD GEAR TO SERVICLE VEHICLES WITH PRODUCTION DATE OF 03/85 TO 08/88.)
- Fitting Vehicle Options: SK(MM5)
94860102
RING, 3RD GEAR BLOCKING(REPAIR-REQUIRED WHEN USING 88973200 3RD GEAR TO SERVICLE VEHICLES WITH PRRODUCTION DATE OF 03/85 TO 08/88)
- Fitting Vehicle Options: SK(MM5)

94840736
WASHER, Transmission Main Shaft Gear, WASHER,1ST GEAR THRUST(38.1MM INSIDE DIAMETER, 52MM OUTSIDE DIAMETER)(6MM THICK)

94840738
SPACER, Transmission Rear Bearing & Mainshaft, SPACER,2ND GEAR BEARING(32.2MM INSIDE DIAMETER, 37MM OUTSIDE DIAMETER)(3.9MM THICK)

94840822
GEAR, Speedometer Drive, GEAR,SPEEDOMETER DRIVE

94842648
PIN, Straight, PIN,SLOTTED SPRING

94842875
BOLT, Transmission Reverse Idler Shaft, BOLT,REV IDLER GEAR SHAFT(M8X1.25X35)

94843201
SHAFT, Transmission Reverse Idler, SHAFT,REV IDLER GEAR

WASHER, Transmission Reverse Idler Gear

94843202
WASHER, REV IDLER GEAR THRUST(18.2MM INSIDE DIAMETER, 29MM OUTSIDE DIAMETER)(3.5MM THICK)
94846128
WASHER, REV IDLER GEAR SHAFT(8.3MM INSIDE DIAMETER, 16.5MM OUTSIDE DIAMETER)(2.0MM THICK)

RING, Transmission Clutch Gear

94843448
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE A)(2.29MM THICK)
94843449
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE B)(2.35MM THICK)
94843450
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE C)(2.41MM THICK)
94843451
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE D)(2.47MM THICK)
94843452
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE E)(2.53MM THICK)
94843453
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE F)(2.59MM THICK)

94843470
RING, Transmission Rear Bearing & Mainshaft, RING,MAIN SHAFT REAR BEARING RETAINER(56.9MM INSIDE DIAMETER, 63.6MM OUTSIDE DIAMETER)(1.8MM THICK)

94844299
SHAFT, Transmission Mainshaft, SHAFT,MAIN

94846039
GEAR,Fourth & Fifth Gear, GEAR,5TH

94850210
SLEEVE, Transmission Synchronizer, SLEEVE,5TH GEAR SYN(USE TOGETHER WITH 94850207 FORK)

94851785
GEAR, Transmission First/Reverse Gear, GEAR,1ST(USE TOGETHER WITH 94853551 RING)

94855309
SHIELD, Transmission Mainshaft Center/Rear, SHIELD,MAIN SHAFT BEARING OIL

94856639
GEAR, Transmission Second Speed, GEAR,2ND(REQUIRES (3) 94844042 INSERT TOGETHER WITH (1) 94853550 RING)

94857179
SLEEVE KIT, Transmission Synchronizer, SLEEVE KIT,3RD & 4TH GEAR SYN
