How to disconnect the negative battery cable and adjust the shift cable on 1981 and later Buick Skylark,Oldsmobile Omega and Pontiac Phoenix?

To disconnect the negative battery cable, shift the transaxle into 1st gear. Then, raise the front of the car and support it on jackstands. Working under the car, loosen the shift cable attaching nuts at the transaxle levers. Move to the interior of the car and remove the console trim plate, sliding the shifter boot up the shifter. Install a yoke clip between the tower and carrier at the base of the shifter, and insert a 5/32 inch or number 22 drill bit into the alignment hole at the side of the shifter assembly. Rotate the transaxle lever and tighten the attaching nut to remove slack from the cable. Tighten the attaching nut on the transaxle, then remove the drill bit and clip from the shifter assembly. Reinstall the shifter boot and console trim plate, and reconnect the negative battery cable. After adjustment, lower the car to the ground and road test, checking for a good neutral gate feel during shifting. If necessary, finer adjustments can be made after road testing.

How to adjust Shift Cable in a Buick Skylark,Oldsmobile Omega and Pontiac Phoenix?

To begin, place the shifter in the 1st gear position. Then, remove the shifter boot and retainer at the control assembly. Install two drill bits into the alignment holes in the control assembly to hold it in 1st gear. Next, attach both shift cables to the control assembly using the studs and pin retainers, ensuring they are routed correctly and operate smoothly. Move to the transaxle and shift it into 1st gear by pushing the rail selector shaft down until you feel the resistance of the inhibitor spring, then rotate the shift lever counterclockwise. Insert the stud on the cable into the shift lever's slotted hole and tighten the retaining nut. Repeat this step for the select lever. Remove the drill bits from the control assembly and road test the car, checking for smooth shifting and engagement of each gear. Fine-tune the adjustment if necessary after the road test.

Genuine Pontiac Phoenix Shift Cable

Transmission Shift Cable

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

11 Shift Cables found

View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 10041214
$62.66 MSRP: $79.79
You Save: $17.13 (22%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Range Selector Lever
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1983-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 25513393
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Throttle Valve
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 1262487
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Throttle Valve
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Parking Lock Cable Assembly
Part Number: 10039713
Product Specifications
- Other Name: Cable Assembly, Automatic Transmission Parking Lock; Interlock Cable
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1983-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable
Part Number: 10027422
Product Specifications
- Other Name: Cable,Automatic Transmission Shift Control ; Cable,A/Trans Shft Cont
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable
Part Number: 10021329
Product Specifications
- Other Name: Cable,Automatic Transmission Shift Control ; Cable,A/Trans Shft Cont
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 14080703
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Range Selector Lever
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable
Part Number: 14080701
Product Specifications
- Other Name: Cable,Automatic Transmission Shift Control ; Cable,A/Trans Shft Cont
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 14080704
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Range Selector Lever
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable Assembly
Part Number: 10023729
Product Specifications
- Other Name: Cable Asm,Automatic Transmission Range Selector Lever
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1983-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L
View related parts
Pontiac Phoenix Automatic Transmission Shifter Cable
Part Number: 14080702
Product Specifications
- Other Name: Cable,Automatic Transmission Shift Control
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1984 Pontiac Phoenix | 2 DOOR, 4 DOOR, LJ 2 DOOR, LJ 4 DOOR | 4 Cyl 2.5L, 6 Cyl 2.8L

Pontiac Phoenix Shift Cable

Each OEM Pontiac Phoenix Shift Cable we offer is competitively priced and comes with the assurance of the manufacturer's warranty for the part. Furthermore, we guarantee the speedy delivery of your orders right to your doorstep. Our hassle-free return policy is also in place for your peace of mind.

Pontiac Phoenix Shift Cable Parts Questions & Experts Answers

Automatic Transmission Shifter Cable Assembly
25513393
Q: How to disconnect the negative battery cable and adjust the shift cable on 1981 and later Buick Skylark,Oldsmobile Omega and Pontiac Phoenix?
A: To disconnect the negative battery cable, shift the transaxle into 1st gear. Then, raise the front of the car and support it on jackstands. Working under the car, loosen the shift cable attaching nuts at the transaxle levers. Move to the interior of the car and remove the console trim plate, sliding the shifter boot up the shifter. Install a yoke clip between the tower and carrier at the base of the shifter, and insert a 5/32 inch or number 22 drill bit into the alignment hole at the side of the shifter assembly. Rotate the transaxle lever and tighten the attaching nut to remove slack from the cable. Tighten the attaching nut on the transaxle, then remove the drill bit and clip from the shifter assembly. Reinstall the shifter boot and console trim plate, and reconnect the negative battery cable. After adjustment, lower the car to the ground and road test, checking for a good neutral gate feel during shifting. If necessary, finer adjustments can be made after road testing.
Automatic Transmission Shifter Cable Assembly
10023729
Q: How to adjust Shift Cable in a Buick Skylark,Oldsmobile Omega and Pontiac Phoenix?
A: To begin, place the shifter in the 1st gear position. Then, remove the shifter boot and retainer at the control assembly. Install two drill bits into the alignment holes in the control assembly to hold it in 1st gear. Next, attach both shift cables to the control assembly using the studs and pin retainers, ensuring they are routed correctly and operate smoothly. Move to the transaxle and shift it into 1st gear by pushing the rail selector shaft down until you feel the resistance of the inhibitor spring, then rotate the shift lever counterclockwise. Insert the stud on the cable into the shift lever's slotted hole and tighten the retaining nut. Repeat this step for the select lever. Remove the drill bits from the control assembly and road test the car, checking for smooth shifting and engagement of each gear. Fine-tune the adjustment if necessary after the road test.

Related Pontiac Phoenix Parts

Browse by Year

1984 Shift Cable 1983 Shift Cable 1982 Shift Cable
