24205900COVER, TORQUE CONVERTER HOUSING ACCESS HOLE(62MM W/3 TANGS)(LARGE COVER)
- Fitting Vehicle Options: G2,3(MYD)
24281668COVER, AUTOMATIC TRANSMISSION CASE FRONT
- Fitting Vehicle Options: G2,3(LV1,M5U)
24281619COVER, AUTOMATIC TRANSMISSION CASE FRONT(MUST BLACK ENAMEL USED TOGETHER WITH SEAL 24281790)
- Fitting Vehicle Options: G2,3(LWN,M5U)
GASKET, Transmission Oil Pan
24260071GASKET, AUTOMATIC TRANSMISSION FLUID PAN
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
24226850GASKET, AUTOMATIC TRANSMISSION FLUID PAN
- Fitting Vehicle Options: G2,3(MYD)
8654382PLUG, AUTOMATIC TRANSMISSION FLUID FILL HOLE(1/8-27 NPTF)(4.104)
24267298PLUG, TRANS OIL LEVEL CHECK(PART OF 49)(M6X1.0)(INCLUDES SEAL)
SEAL, Rear Bearing Retaining
24226707SEAL, PROPELLER SHAFT FRONT SLIP YOKE OIL(PART OF 34)(*KIT1)
- Fitting Vehicle Options: G2,3(LC8,L96,MYD)
24224675SEAL, AUTOMATIC TRANSMISSION CASE EXTENSION(*KIT1)
- Fitting Vehicle Options: G2,3(MYD)
24265798SEAL, AUTOMATIC TRANSMISSION CASE EXTENSION
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
CONVERTER, Transmission Converter
17804388CONVERTER, TORQUE(REMANUFACTURED-NOT FOR SALE WHERE IMPORTS ARE RESTRICTED)
- Fitting Vehicle Options: G2,3(LC8,L96,MYD)
- Replaced By: 19435560
EXTENSION, Transmission Case
24287641EXTENSION, AUTOMATIC TRANSMISSION CASE
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
24226703EXTENSION, AUTOMATIC TRANSMISSION CASE(INCLUDES 35,36)
- Fitting Vehicle Options: G2,3(MYD)
PAN, Transmission Oil Pan
24278774PAN, AUTOMATIC TRANSMISSION FLUID(INCLUDES 50)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
- Replaced By: 24045035
24226851PAN, AUTOMATIC TRANSMISSION FLUID
- Fitting Vehicle Options: G2,3(MYD)
24288793SUPPORT, Transmission Converter, SUPPORT,STATOR SHAFT(NEW CALIBRATE REQ. REFER TO BUL 12-NAME-007: DELAYED ENGAGEMENT, FIRM GARAGE SHIFTS, START UP CLUNK DTC P16F3 (REPROGRAM TCM)COVERS OTHER FIXES IN SERVICE.)(INCLUDES 13)
SEAL, Transmission Oil Cooler
15251488SEAL, TRANS FLUID COOLER PIPE FITTING(SEALS TWO PIPES)
- Fitting Vehicle Options: G2,3(LC8,L96)
23135703SEAL, TRANS FLUID COOLER PIPE FITTING(AT TRANS)
- Fitting Vehicle Options: G334,337(LWN), G2,3(LV1,M5U)
- Replaced By: 85628205
24237658SEAL, TRANS FLUID COOLER PIPE FITTING(AT PIPE)(SEALS ONE PIPE)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
- Require Quantity: 02
- Package Quantity: 1
SEAL, Transmission Front Servo
24266709SEAL, TORQUE CONVERTER FLUID(PART OF 7)(FRONT)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
24224577SEAL, AUTOMATIC TRANSMISSION FLUID PUMP
- Fitting Vehicle Options: G2,3(MYD)
24259216SEAL, TORQUE CONVERTER FLUID(REAR SEAL)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
BOLT, Transmission Converter
24224574BOLT, TORQUE CONVERTER HOUSING
- Fitting Vehicle Options: G2,3(MYD)
- Require Quantity: 09
- Package Quantity: 1
11547864BOLT, STATOR SHAFT SUPPORT(4.226)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
- Require Quantity: 09
- Package Quantity: 1
BOLT, Transmission Planet
11548404BOLT, AUTOMATIC TRANSMISSION FLUID BAFFLE(PART OF 11)(4.105)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
- Require Quantity: 02
- Package Quantity: 1
11548404BOLT, AUTOMATIC TRANSMISSION FLUID BAFFLE(4.105)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
- Require Quantity: 02
- Package Quantity: 1
BOLT, Transmission Main Control Valve Body
11612186BOLT, VALVE BODY(M5X.8X55)(HEXAGON FLANGE)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
- Require Quantity: 19
- Package Quantity: 1
24237181BOLT, VALVE BODY(M5X0.8X73.0)
- Fitting Vehicle Options: G2,3(MYD)
- Require Quantity: 06
- Package Quantity: 1
11612185BOLT, VALVE BODY(M6X1X68)(TORX FLNGE)
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
- Require Quantity: 07
- Package Quantity: 1
SHAFT, Transmission Park Lock
24272978SHAFT, PARKING PAWL
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
BOLT, Transmission Throttle Valve
24231074BOLT, MANUAL SHIFT DETENT(M10X1X14.5)
- Fitting Vehicle Options: G2,3(MYD)
24256684BOLT, MANUAL SHIFT DETENT SPRING(M6X1X25 21 THREAD)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
24236927SEAL KIT, Transmission Overhaul, SEAL KIT,AUTOMATIC TRANSMISSION SERVICE(INCLUDES 9,10,18-20)(FAILURE TO FOLLOW GM SERVICE BULLETIN 09-07-30-005 MAY RESULT IN THEREJECTION OF A WARRANTY CLAIM)(CNTRL SOLENOID VALVE ASM)
ACTUATOR, Transmission Parking Brake
24242088ACTUATOR, PARKING PAWL
- Fitting Vehicle Options: G2,3(MYD)
- Replaced By: 24280047
24279985ACTUATOR, PARKING PAWL(TSB 19-NAME-035 APPLIES TO THIS PART #. PER GM SERVICE POLICIES & PROCEDURES, FAILURE TO FOLLOW THE TSB MAY RESULT IN REJECTION OF A WARRANTY CLAIM.)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
SEAL, Transmission High Clutch
24259218SEAL, CLUTCH HOUSING FLUID PASSAGE(5 INSIDE DIAMETER NOTCHES, 23.1MM TALL)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
24262438SEAL, CLUTCH HOUSING FLUID PASSAGE(0 INSIDE DIAMETER NOTCHES, 33.5 MM TALL)
- Fitting Vehicle Options: G2,3(LV1,M5U)
PIN, Transmission Main Control Valve Body
24263431PIN, CONTROL VALVE BODY LOCATING
- Fitting Vehicle Options: G2,3(LV1,M5U)
- Require Quantity: 02
- Package Quantity: 1
24263431PIN, CONTROL VALVE BODY LOCATING
- Fitting Vehicle Options: G2,3(LWN,M5U)
- Require Quantity: 06
- Package Quantity: 1
24266366SEAL, AUTOMATIC TRANSMISSION CASE FRONT COVER(PART OF 7)
- Fitting Vehicle Options: G2,3(LV1,M5U)
24281790SEAL, AUTOMATIC TRANSMISSION CASE FRONT COVER(PART OF 7)(TO BLACK ENAMEL USED TOGETHER WITH 24286466 OR 24281619)
- Fitting Vehicle Options: G2,3(LWN,M5U)
24289624CASE, AUTOMATIC TRANSMISSION (MACHINING)(WHEN REPLACE CASE, PINS MUST BLACK ENAMEL REPLACE W/CASE: MANUAL SFT SHAFT PINION QTY (1), MANUAL SHIFT DETENT LEVER PINION QTY (1), & CONTROL VALVE BODY LOCATING PINION QTY (2)
- Fitting Vehicle Options: G2,3(LV1,M5U)
24289625CASE, AUTOMATIC TRANSMISSION (MACHINING)(WHEN REPLACE CASE, PINS MUST BLACK ENAMEL REPLACE W/CASE: MANUAL SFT SHAFT PINION QTY (1), MANUAL SHIFT DETENT LEVER PINION QTY (1), & CONTROL VALVE BODY LOCATING PINION QTY (2)
- Fitting Vehicle Options: G2,3(LWN,M5U)
24290675CASE, AUTOMATIC TRANSMISSION(INCLUDES 501,502)(2WD)
- Fitting Vehicle Options: G2,3(MYD)
24290675CASE, AUTOMATIC TRANSMISSION(INCLUDES 12,13)(2WD)
- Fitting Vehicle Options: G2,3(MYD)
24293387PAWL, Transmission Park Lock, PAWL,PARKING(TSB 19-NAME-035 APPLIES TO THIS PART #. PER GM SERVICE POLICIES & PROCEDURES, FAILURE TO FOLLOW THE TSB MAY RESULT IN REJECTION OF A WARRANTY CLAIM.)
24293689HARNESS, AUTOMATIC TRANSMISSION OUTPUT SPEED SENSOR WIRING(NOT A KIT. COMPLETE OUTPUT SPEED SNSR ASM ONLY. ATTN PARTS DEPT: THE RECIPIENT OF THIS PART MUST BLACK ENAMEL INFORMED THAT NEW BOLTS ARE REQ (SEE ILL# 38)
- Fitting Vehicle Options: G2,3(LV1,M5U), G2,3(LWN,M5U)
24297371HARNESS, AUTOMATIC TRANSMISSION WIRING(2-PC,PASS-THROUGH,NON-ESS,4-PINION & 10-PINION)(ORDER TOGETHER WITH 24297371 (2-PC PASS-THROUGH) & 24298757 (2-PC SOLENOID) OR 24298758 (2-PC SOLENOID))
- Fitting Vehicle Options: G2,3(LWN,M5U), G2,3(LV1,M5U)
- Replaced By: 24045609
24042443VALVE, Transmission Main Control Valve Body, VALVE,CONTROL(W/BODY & VALVE)(NON-ESS/NON-ACCUMULATOR)(TCM PROGRAMMING REQ)(ORDER TOGETHER WITH 24293827)(DOES NOT INCLUDE SOLENOID WIRING HARNESS ASM AND/OR A PASS THROUGH WIRING HARNESS ASM.IF EITHER OR BOTH OF THE WIRING HARNESS ASM REQ SERVICE. DEALER MUST ORDER SEPARATOR.)
WASHER, Transmission Sprocket (Front Wheel Drive)
Standard Parts
11515768BOLT, HEX FLANGED HEAD,REDUCED BODY,M10X1.5X40,30THD,22.3 O.D.,HEADER POINT,10.9,7114M(AUTOMATIC TRANSMISSION CASE EXTENSION)
- Require Quantity: 06
- Package Quantity: 10
11515768BOLT, HEX FLANGED HEAD,REDUCED BODY,M10X1.5X40,30THD,22.3 O.D.,HEADER POINT,10.9,7114M(AUTOMATIC TRANSMISSION CASE EXTENSION)
11588712BOLT, HEX FLANGED HEAD,M6X1X20,17.5 THREAD,14.2 O.D.,8.8, GMW3359(AUTOMATIC TRANSMISSION FLUID PAN)
11589299BOLT, HEX FLANGED HEAD,M6X1X19,11.5 THREAD,14.2 OUTSIDE DIAMETER,8.8 STEEL, GMW3359(AUTOMATIC TRANSMISSION FLUID PAN)
- Require Quantity: 18
- Package Quantity: 1
