Part No. & Part Description
Price
Part No. &
Part Description
CLIP, Transmission Oil Cooler
15068848CLIP, TRANS FLUID COOLER PIPE(PART OF 6)(HOLDS 2-9.5MM(3/8") DIAMETER PIPES,CLIP TOP,PLASTIC)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
- Require Quantity:
02
- Package Quantity:
1
15068848CLIP, TRANS FLUID COOLER PIPE(PART OF 5)(HOLDS 2-9.5MM(3/8") DIAMETER PIPES,CLIP TOP,PLASTIC)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N)
- Require Quantity:
02
- Package Quantity:
1
15068848CLIP, TRANS FLUID COOLER PIPE(PART OF 7)(HOLDS 2-9.5MM(3/8") DIAMETER PIPES,CLIP TOP,PLASTIC)
- Fitting Vehicle Options:
KL69(HP9)
- Require Quantity:
02
- Package Quantity:
1
11610677CLIP, TRANS FLUID COOLER PIPE(PART OF 6)(W/INSERT,HOLDS TWO 9.5 DIAMETER TUBES,FITS 8.0 DIAMETER HOLE)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
- Replaced By:
11546932
11610677CLIP, TRANS FLUID COOLER PIPE(PART OF 5)(W/INSERT,HOLDS TWO 9.5 DIAMETER TUBES,FITS 8.0 DIAMETER HOLE)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N)
- Require Quantity:
02
- Package Quantity:
1
- Replaced By:
11546932
11610677CLIP, TRANS FLUID COOLER PIPE(PART OF 7)(W/INSERT,HOLDS TWO 9.5 DIAMETER TUBES,FITS 8.0 DIAMETER HOLE)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
11546932
11547871CLIP, TRANS FLUID COOLER PIPE(PART OF 6)(HOLDS ONE 9.5MM, 3/8" TUBE, PLASTIC TREE FOR 9.5 HOLE)(3.145)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
- Require Quantity:
03
- Package Quantity:
1
11547871CLIP, TRANS FLUID COOLER PIPE(PART OF 7)(HOLDS ONE 9.5MM, 3/8" TUBE, PLASTIC TREE FOR 9.5 HOLE)(3.145)
- Fitting Vehicle Options:
KL69(HP9)
- Require Quantity:
04
- Package Quantity:
1
13312826CLIP, TRANS FLUID COOLER PIPE(PART OF 5)(PUSH-IN)(HOLDS 9.5 DIAMETER LINE)(9.242)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N)
- Require Quantity:
04
- Package Quantity:
1
VALVE, Transmission Oil Cooler
13511137VALVE, TRANS FLUID COOLER THERMAL BYPASS(PART OF 5)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
13561467
13511137VALVE, TRANS FLUID COOLER THERMAL BYPASS(PART OF 7)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
13561467
13511136VALVE, TRANS FLUID COOLER THERMAL BYPASS(PART OF 6)(IF VEHICLE HAS QUICK CONNECTS MUST ORDER PIPE ASSEMBLY PER VIN)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
- Replaced By:
85585333
13511136VALVE, TRANS FLUID COOLER THERMAL BYPASS(PART OF 5)(IF VEHICLE HAS QUICK CONNECTS MUST ORDER PIPE ASSEMBLY PER VIN)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N), KH,KJ69(LTG,M5N)
- Replaced By:
85585333
SEAL, Transmission Oil Cooler
23135703SEAL, TRANS FLUID COOLER PIPE FITTING(PART OF 6)(AT TRANS)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
- Replaced By:
85628205
23135703SEAL, TRANS FLUID COOLER PIPE FITTING(PART OF 5)(AT TRANS)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N)
- Replaced By:
85628205
23135703SEAL, TRANS FLUID COOLER PIPE FITTING(PART OF 7)(AT TRANS)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
85628205
23277649SEAL, TRANS FLUID COOLER PIPE FITTING(O RING)(PART OF 7)
- Fitting Vehicle Options:
KL69(HP9)
- Require Quantity:
02
- Package Quantity:
1
FITTING, Transmission Oil Cooler
23385886FITTING, TRANS FLUID COOLER PIPE(PART OF 14)(INCLUDES 2)
- Fitting Vehicle Options:
KH,KJ69(LTG)
- Require Quantity:
02
- Package Quantity:
1
23385886FITTING, TRANS FLUID COOLER PIPE(PART OF 12)(INCLUDES 2)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW), KH,KJ,KL,KM69(LGX)
- Require Quantity:
02
- Package Quantity:
1
23385886FITTING, TRANS FLUID COOLER PIPE(PART OF 1)
- Fitting Vehicle Options:
KL69(LTG)
- Require Quantity:
02
- Package Quantity:
1
RETAINER, Transmission Oil Cooler
23385887RETAINER, TRANS FLUID AUXILIARY COOLER(PART OF 1,14)
- Fitting Vehicle Options:
KH,KJ(LTG)
- Require Quantity:
02
- Package Quantity:
1
23385887RETAINER, TRANS FLUID AUXILIARY COOLER(PART OF 1,12)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW), KH,KJ,KL,KM69(LGX)
- Require Quantity:
02
- Package Quantity:
1
23385887RETAINER, TRANS FLUID AUXILIARY COOLER(PART OF 1)
- Fitting Vehicle Options:
KL(LTG)
- Require Quantity:
02
- Package Quantity:
1
PIPE, Transmission Oil Cooler
84013047PIPE, TRANS FLUID COOLER INLET & OUTLET(INCLUDES 3-5,9,11-13)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
84013047PIPE, TRANS FLUID COOLER INLET & OUTLET(INCLUDES 3,4,6,7,9-11)
- Fitting Vehicle Options:
KH,KJ69(LTG,M5N)
84013049PIPE, TRANS FLUID COOLER INLET & OUTLET(INCLUDES 3,4,6,7,9-11)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
84161152
84013049PIPE, TRANS FLUID COOLER INLET & OUTLET(INCLUDES 4,6,8,11-17)
- Fitting Vehicle Options:
KL69(HP9)
- Replaced By:
84161152
84161153PIPE, TRANS FLUID COOLER INLET & OUTLET(INCLUDES 3,4,6,7,9-11)
- Fitting Vehicle Options:
KH,KL,KM69(LGW,M5X), KJ,KL,KM69(LGW,M5X), KH,KJ,KL,KM69(LGX,M5N)
- Replaced By:
84440484
COOLER, Transmission Oil Cooler
84360132COOLER, TRANS FLUID AUXILIARY(INCLUDES 1,2)
- Fitting Vehicle Options:
KH,KJ69(LTG), KJ,KL,KM69(LGW), KH,KJ,KL,KM69(LGX)
84360132COOLER, TRANS FLUID AUXILIARY(INCLUDES 2,3,5)
- Fitting Vehicle Options:
KL(LTG)
Standard Parts
11588711BOLT, HEX FLANGED HEAD,M6X1X16, 10 THREAD, 14.2 OUTSIDE DIAMETER, 8.8 STEEL, GMW3359(PART OF 6)
11588711BOLT, HEX FLANGED HEAD,M6X1X16, 10 THREAD, 14.2 OUTSIDE DIAMETER, 8.8 STEEL, GMW3359(PART OF 5)
11588711BOLT, HEX FLANGED HEAD,M6X1X16, 10 THREAD, 14.2 OUTSIDE DIAMETER, 8.8 STEEL, GMW3359(PART OF 7)
11588712BOLT, HEX FLANGED HEAD,M6X1X20,17.5 THREAD,14.2 O.D.,8.8, GMW3359(ENGINE OIL COOLER PIPE BRACKET)
11519387BOLT, HWASH,M8X1.25X20,14 THREAD,24 OUTSIDE DIAMETER,GMW25(8.8)STEEL,GMW3359,M-POINT.(TRANS FLUID COOLER PIPE BRACKET)
11588729BOLT, HEXAGON HEAD, W/1.6 FLAT WASHER,M8X1.25X54.3,43 THREAD,16O.D.,8.8,GMW3359(TRANS FLUID COOLER THERMAL BYPASS VALVE)
11588729BOLT, HEXAGON HEAD, W/1.6 FLAT WASHER,M8X1.25X54.3,43 THREAD,16O.D.,8.8,GMW3359(TRANS FLUID COOLER THERMAL BYPASS)
11588729BOLT, HEXAGON HEAD, W/1.6 FLAT WASHER,M8X1.25X54.3,43 THREAD,16O.D.,8.8,GMW3359(PART OF 7)
Genuine GM Parts, the Right Choice
GMPartsGiant.com offers the wholesale prices for genuine 2017
Cadillac CT6 parts. Parts like Automatic Transmission Oil Cooler Pipes are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.0L, 6 Cyl 3.0L, 6 Cyl 3.6L. Model Code: 4 DOOR SEDAN, BASE 4 DOOR SEDAN, PLATINUM 4 DOOR SEDAN, PREMIUM 4 DOOR SEDAN.
