Hoses & Pipes/Heater fit your 2004 Buick Rendezvous

Currently shopping for

2004 Buick Rendezvous

Change Vehicle

Categories Close X

Currently selected

Front End Sheet Metal, Heater

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Maintenance Parts, Fluids, Capacities, Electrical Connectors

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transfer Case

Transmission - Automatic

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

Parts Questions

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

12636104
GASKET, Heater, GASKET,HEATER OUTLET PIPE(PART OF 5)
$11.38 $6.03
1
Add To Cart

HOSE, Throttle Body Coolant Supply

24504912
HOSE, THROTTLE BODY HEATER INLET(9MM INSIDE DIAMETER 3MM WALL)(FORMED 90 DEGREE BEND,43.5 LONG EACH END)
$17.55 $9.79
1
Add To Cart
24504913
HOSE, THROTTLE BODY HEATER OUTLET
$27.62 $14.63
1
Add To Cart

10189205
SEAL, Engine Coolant By-Pass, SEAL,THERMOSTAT BYPASS PIPE ADAPTER (O RING)(PART OF 15)(YELLOW)
$14.42 $12.60
1
Add To Cart

PIPE, Engine Coolant By-Pass
24507950
PIPE, THERMOSTAT BYPASS(INCLUDES 16,18)(W/O OIL COOLER)
Fitting Vehicle Options: B(LA1)(EXC KC4)
$69.11 $43.92
1
Add To Cart
12590279
PIPE, THERMOSTAT BYPASS(PART OF LOWER INTAKE)(USE SEALANT 19332211(USA) OR 10953488(CANADA)
- Fitting Vehicle Options: B(LA1)
$57.81 $36.74
1
Add To Cart
24507951
PIPE, THERMOSTAT BYPASS(INCLUDES 16,18)
- Fitting Vehicle Options: B(LA1,KC4)
$61.18 $38.88

10070107
VALVE, Engine Air Cooling Control, VALVE,ENGINE COOLANT AIR BLEED(PART OF 15)
- Require Quantity: 02
- Package Quantity: 1
$18.78 $10.47
1
Add To Cart

10182356
HOSE, Engine Coolant By-Pass, HOSE,THERMOSTAT BYPASS
$23.15 $14.72
1
Add To Cart

SEAL, Heater
24504709
SEAL, HEATER INLET PIPE ADAPTER (O RING)(PART OF 7)(OUTER DIAMETER 0.549" INNER DIAMETER 0.103" X-SECTION DIAMETER)(3.337)
Fitting Vehicle Options: B(LA1,JJA)
$5.16 $2.88
10
Add To Cart
19351800
SEAL, HEATER OUTLET PIPE (O RING)(PART OF 5)
- Fitting Vehicle Options: B(LY7)
$7.39 $4.69
1
Add To Cart

HOSE, Heater
10324109
HOSE, HEATER OUTLET(INCLUDES 3)
Fitting Vehicle Options: B(LA1)
Replaced By: 19431991
$47.36 $26.40
1
Add To Cart
10324108
HOSE, HEATER INLET(INCLUDES 4,6)
- Fitting Vehicle Options: B(LA1)
- Replaced By: 19431990
$106.00 $50.46
1
Add To Cart
10314360
HOSE, HEATER INLET(INCLUDES 3)
- Fitting Vehicle Options: B(LY7,CJ2)
10314361
HOSE, HEATER OUTLET(INCLUDES 2)
- Fitting Vehicle Options: B(LY7,CJ2)

PIPE, Heater
12568744
PIPE, HEATER INLET(INCLUDES 9)
Fitting Vehicle Options: B(LA1,JJA)
$75.82 $40.18
1
Add To Cart
12597533
PIPE, HEATER INLET & OUTLET(INCLUDES 6-9)
- Fitting Vehicle Options: B(LY7)

12574365
FLANGE, Heater, FLANGE,HEATER INLET PIPE(PART OF 5)
$5.07 $2.86
1
Add To Cart

CLAMP, Throttle Body Coolant Supply
24506377
CLAMP, THROTTLE BODY HEATER OUTLET HOSE(SPRING BAND,14.9-17.5 1D,1 THICK BAND,10 WIDE,MODIFIED SAE 6150)(1.540)
Require Quantity: 02
Package Quantity: 1
24506377
CLAMP, THROTTLE BODY HEATER INLET HOSE(SPRING BAND,14.9-17.5 1D,1 THICK BAND,10 WIDE,MODIFIED SAE 6150)(1.540)
- Require Quantity: 02
- Package Quantity: 1

11514596
NUT, HEX FLANGED HEAD,M8X1.25,17.9 OUTSIDE DIAMETER,738 THICK,13MM HEXAGON,10, PHOSPHATE ZINC ORGANIC - FLAKE(THERMOSTAT BYPASS PIPE CLIP)(8.915)
$12.60
1
Add To Cart

11514596
NUT, HEX FLANGED HEAD,M8X1.25,17.9 OUTSIDE DIAMETER,738 THICK,13MM HEXAGON,10, PHOSPHATE ZINC ORGANIC - FLAKE(HEATER INLET PIPE)(8.915)
$12.60
1
Add To Cart

11561025
BOLT, HEX FLANGED HEAD,M6X1X16,13.5 THREAD,14.2 OUTSIDE DIAMETER,GMW25 STEEL,GMW3200,MACHINE,HEADER POINT(THERMOSTAT BYPASS PIPE)
$9.15 $5.81
1
Add To Cart

11561026
BOLT, HEX FLANGED HEAD,THREAD,14.2 OUTSIDE DIAMETER,9.8,GMW3200,MACHINE,HEADER POINT(PART OF 5)
- Require Quantity: 02
- Package Quantity: 1
$36.02 $22.89
1
Add To Cart

11570616
CLAMP, SPRINGBAND, 27 NOMINAL DIAMETER, 15 THICK, STEEL, ROBO(PART OF 5)
$7.19 $4.57
1
Add To Cart

11570616
CLAMP, SPRINGBAND, 27 NOMINAL DIAMETER, 15 THICK, STEEL, ROBO(PART OF 4)
$7.19 $4.57
1
Add To Cart

11570383
CLAMP, SPRINGBAND,24 NOMINAL DIAMETER, 15 THICK, STEEL, GMW14083(HEATER OUTLET HOSE)
$41.38 $20.85
1
Add To Cart

11570383
CLAMP, SPRINGBAND,24 NOMINAL DIAMETER, 15 THICK, STEEL, GMW14083(PART OF 1)
$41.38 $20.85
1
Add To Cart

1470030
CLAMP, WORM TYPE(11/16" TO 1 5/16")(THERMOSTAT BYPASS PIPE)
- Require Quantity: 02
- Package Quantity: 1
- Replaced By: 11610236
$7.38 $4.69
1
Add To Cart

11517518
BOLT, HEX FLANGED HEAD,M6X1X20,17.9 THREAD,14.2 O.D.,9.8,TIN ZINC(THERMOSTAT BYPASS PIPE)
$12.60
1
Add To Cart

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2004 Buick Rendezvous parts. Parts like Hoses & Pipes/Heater are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 3.4L, 6 Cyl 3.6L. Model Code: AWD, RENDEZVOUS.
