Part No. & Part Description
Price & Qty.
Part No. &
Part Description
22514722SEAL, FUEL FEED PIPE(O RING)(PART OF PIPE,FEED & RETURN ASM BUNDLE)(7.35MM INSIDE DIAMETER X 1.66MM THICK)
- Fitting Vehicle Options: J
17103631SEAL, FUEL INJECTION FUEL RETURN PIPE(O RING)
- Fitting Vehicle Options: J(LD9)
RETAINER, Hydraulic Brake Pipe
22604606RETAINER, BRAKE & FUEL PIPE(POSITION #24)(3.162)(USE W/1ST DESIGN PIPE 22615288)
22621892RETAINER, BRAKE & FUEL PIPE(POSITION 24)(3.162)(USE W/2ND DESIGN PIPE 22617966)
22604606RETAINER, BRAKE & FUEL PIPE(POSITION #24)(USE W/1ST DESIGN PIPE 22615288)
22621892RETAINER, BRAKE & FUEL PIPE(POSITION 24)(USE W/2ND DESIGN PIPE 22617966)
24575564PIPE, FUEL INJECTION FUEL RETURN(WHITE TAPE)
- Fitting Vehicle Options: J(LD9)
24576476PIPE, FUEL INJECTION FUEL FEED(GRAY TAPE)(W/O ACCUMULATOR)
- Fitting Vehicle Options: J(LD9)
22615288PIPE, BRAKE & FUEL FEED & FUEL RETURN & EVAP EMISSION(INCLUDES 13,15)(ATTACHES TO EVAP CANISTER ABOVE VENT SOLENOID, FOR 2ND DESIGN SEE 22617966)
- Fitting Vehicle Options: J(1ST DES)
22617966PIPE, BRAKE & FUEL FEED & FUEL RETURN & EVAP EMISSION(INCLUDES 13,15)(ATTACHES TO EVAP CANISTER BELOW VENT SOLENOID, FOR 1ST DESIGN SEE 22615288)
- Fitting Vehicle Options: J(2ND DES)
24576584PIPE, FUEL INJECTION FUEL RETURN
- Fitting Vehicle Options: J(LN2)
22615288PIPE, BRAKE & FUEL FEED & FUEL RETURN & EVAP EMISSION(INCLUDES 13,15)(ATTACHES TO EVAP CANISTER ABOVE VENT SOLENOID, FOR 2ND DESIGN SEE 22617966)
- Fitting Vehicle Options: J(1ST DES)
22617966PIPE, BRAKE & FUEL FEED & FUEL RETURN & EVAP EMISSION(INCLUDES 13,15)(ATTACHES TO EVAP CANISTER BELOW VENT SOLENOID, FOR 1ST DESIGN SEE 22615288)
- Fitting Vehicle Options: J(2ND DES)
24572092CLIP, FUEL INJECTION FUEL FEED & RETURN PIPE(TO BRACKET & LIFT HOOK)(FUEL RAIL BOLT HOLE)
- Fitting Vehicle Options: J(LD9)
24572092CLIP, FUEL INJECTION FUEL FEED & RETURN PIPE(TO BRACKET & LIFT HOOK)(TO BRACKET & LIFT HOOK)
- Fitting Vehicle Options: J(LD9)
24575247CLIP, FUEL INJECTION FUEL FEED & RETURN PIPE(FUEL RAIL BOLT HOLE)(FUEL RAIL BOLT HOLE)
- Fitting Vehicle Options: J
24575247CLIP, FUEL INJECTION FUEL FEED & RETURN PIPE(FUEL RAIL BOLT HOLE)(TO BRACKET & LIFT HOOK)
- Fitting Vehicle Options: J
HARNESS, Early Fuel Evaporation
24576412HARNESS, EVAP EMISSION CANISTER PURGE SOLENOID VALVE(SEE GROUP 03.000 "VAPOR CANISTER & RELATED PARTS" FOR DETAILED ILLUSTRATED VIEW)
- Fitting Vehicle Options: J(LN2)
24577676HARNESS, EVAP EMISSION CANISTER(SEE GROUP 03.000 "VAPOR CANISTER & RELATED PARTS" FOR DETAILED ILLUSTRATED VIEW.)
- Fitting Vehicle Options: J(LD9)
Standard Parts
11515760BOLT, M8X1.25X40,18 O.D.,22THD,9.8,7114M(INTAKE MANIFOLD)
12337828SCREW, HEXAGON W/FLAT WASHER,TAP,M6.3X1.81X20,13.2 O.D.,ALUMINUM BASECOAT POINT,STEEL,PZ0R(POSITION #15,20,21,22,23 & 24)
- Require Quantity: 06
- Package Quantity: 1
- Replaced By: 22527475
11518061BOLT, HEX FLANGED HEAD, M6X1X13, 10 THREAD, 14.2 OUTSIDE DIAMETER, GMW25M(8.8) STEEL,GMW14C-POINT(FUEL INJECTION FUEL FEED & RETURN PIPE CLIP)
Genuine GM Parts, the Right Choice
GMPartsGiant.com offers the wholesale prices for genuine 1999
Chevrolet Cavalier parts. Parts like Fuel Supply System are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.2L, 4 Cyl 2.4L. Model Code: 2 DOOR, 4 DOOR, CONVERTIBLE, LS 4 DOOR, Z24 2 DOOR.
