How do you remove the headlight housing on Buick Enclave,Chevrolet Traverse and GMC Acadia?

Disconnect the cable from the negative battery terminal. Remove the front bumper cover. Remove the headlight housing mounting bolts. Gently pull the headlight housing from the radiator support, then disconnect the electrical connector. Installation is the reverse of removal. If you are reusing the original headlight assemblies, there is no need to readjust the headlight aim. But if you are replacing the assemblies, set the adjustment cam to its base setting about six turns from completely seated. This will aid in aligning the bumper cover.

How can headlights and fog lights be adjusted for proper alignment and optimal visibility for Buick Enclave,Chevrolet Traverse and GMC Acadia?

Headlights and fog lights can be adjusted to ensure proper alignment and optimal visibility. For composite headlights, there are adjustment screws that control the up-and-down movement, but left-and-right movement is not adjustable. To adjust the headlights, a blank wall 25 feet in front of the vehicle and a level floor are needed. Position masking tape on the wall in reference to the vehicle centerline and the centerlines of both headlights. Measure the height of the headlight reference marks from the ground and position a horizontal tape line on the wall at the same height. With the vehicle sitting level, the gas tank half-full, and no heavy load, turn on the low beams and adjust the adjusting screw to position the high-intensity zone eight inches below the horizontal line. To ensure proper adjustment, it is recommended to have the headlights adjusted professionally. Similarly, fog lights can also be adjusted like headlights. Position tape on a wall 25 feet in front of the vehicle and tape a horizontal line representing the height of the fog light centers, as well as another line four inches below. Remove the fasteners from the front portion of the inner fender splash shield to access the adjustment screws for the fog lights. Adjust the pattern on the wall so that the top of the fog light beam meets the lower line.

Genuine Chevrolet Traverse Headlight

Headlamp

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

14 Headlights found

View related parts
Chevrolet Traverse Capsule/Headlamp/Fog Lamp Headlamp
Part Number: 20794801
$262.03 MSRP: $393.51
You Save: $131.48 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Asm ; Headlamp, Capsule/Headlamp/Fog Lamp; Composite Assembly, Headlamp Assembly
- Replaces: 25851946
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE 4WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84262932
$468.08 MSRP: $702.19
You Save: $234.11 (34%)
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaces: 20971880, 23235886, 23402605, 23458558, 23202710
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2013-2017 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L
View related parts
Chevrolet Traverse Headlamp Assembly, Front
Part Number: 84887857
$877.46 MSRP: $1319.78
You Save: $442.32 (34%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaces: 84573719, 84342151, 84524240, 84721414, 84289677, 84390861, 84685648
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Headlamp Assembly, Front
Part Number: 84887858
$877.46 MSRP: $1319.78
You Save: $442.32 (34%)
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaces: 84342152, 84685649, 84524241, 84289678, 84390862, 84721415, 84573720
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84721418
$851.27 MSRP: $1280.26
You Save: $428.99 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt
- Position: Front
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Capsule/Headlamp/Fog Lamp Headlamp
Part Number: 20794802
$250.22 MSRP: $393.51
You Save: $143.29 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Asm ; Headlamp, Capsule/Headlamp/Fog Lamp; Composite Assembly, Headlamp Assembly
- Replaces: 25851947
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE 4WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84390859
$851.27 MSRP: $1280.26
You Save: $428.99 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Front
- Position: Front
- Replaced by: 84721418
- Replaces: 84342149
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84390860
$400.35 MSRP: $597.30
You Save: $196.95 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Front
- Position: Front
- Replaced by: 84721419
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84721419
$400.35 MSRP: $597.30
You Save: $196.95 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt
- Position: Front
- Replaces: 84342150, 84685653, 84390860
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LS EXTENDED 4 DOOR SUV, LT EXTENDED 4 DOOR SUV, LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Headlamp Assembly, Front
Part Number: 84721416
$941.22 MSRP: $1415.97
You Save: $474.75 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaced by: 84887859
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Front Headlight Assembly
Part Number: 84262931
$468.08 MSRP: $702.19
You Save: $234.11 (34%)
ADD TO CART
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaces: 23402604, 23235887, 20971879, 23458559, 23202709
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2013-2017 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L
View related parts
Chevrolet Traverse Headlamp Assembly, Front
Part Number: 84887860
$941.22 MSRP: $1415.97
You Save: $474.75 (34%)
Product Specifications
- Other Name: Headlamp Assembly, Frt; Composite Assembly, Headlamp Assembly
- Position: Front
- Replaces: 84289682, 84342154, 84524243, 84721417, 84390864, 84685651, 84573724
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2021 Chevrolet Traverse | LTZ EXTENDED 4 DOOR SUV | 4 Cyl 2.0L, 6 Cyl 3.6L
View related parts
Chevrolet Traverse Capsule/Headlamp/Fog Lamp Headlamp
Part Number: 20794803
Product Specifications
- Other Name: Headlamp Asm ; Headlamp, Capsule/Headlamp/Fog Lamp; Composite Assembly, Headlamp Assembly
- Replaces: 25851948
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE 4WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L
View related parts
Chevrolet Traverse Capsule/Headlamp/Fog Lamp Headlamp
Part Number: 20794804
Product Specifications
- Other Name: Headlamp Asm ; Headlamp, Capsule/Headlamp/Fog Lamp; Composite Assembly, Headlamp Assembly
- Replaces: 25851949
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Traverse | SPORT UTILITY VEHICLE 2WD, SPORT UTILITY VEHICLE 4WD, SPORT UTILITY VEHICLE AWD | 6 Cyl 3.6L

Chevrolet Traverse Headlight Parts Questions & Experts Answers

Capsule/Headlamp/Fog Lamp Headlamp
20794801
Q: How do you remove the headlight housing on Buick Enclave,Chevrolet Traverse and GMC Acadia?
A: Disconnect the cable from the negative battery terminal. Remove the front bumper cover. Remove the headlight housing mounting bolts. Gently pull the headlight housing from the radiator support, then disconnect the electrical connector. Installation is the reverse of removal. If you are reusing the original headlight assemblies, there is no need to readjust the headlight aim. But if you are replacing the assemblies, set the adjustment cam to its base setting about six turns from completely seated. This will aid in aligning the bumper cover.
Capsule/Headlamp/Fog Lamp Headlamp
20794801
Q: How can headlights and fog lights be adjusted for proper alignment and optimal visibility for Buick Enclave,Chevrolet Traverse and GMC Acadia?
A: Headlights and fog lights can be adjusted to ensure proper alignment and optimal visibility. For composite headlights, there are adjustment screws that control the up-and-down movement, but left-and-right movement is not adjustable. To adjust the headlights, a blank wall 25 feet in front of the vehicle and a level floor are needed. Position masking tape on the wall in reference to the vehicle centerline and the centerlines of both headlights. Measure the height of the headlight reference marks from the ground and position a horizontal tape line on the wall at the same height. With the vehicle sitting level, the gas tank half-full, and no heavy load, turn on the low beams and adjust the adjusting screw to position the high-intensity zone eight inches below the horizontal line. To ensure proper adjustment, it is recommended to have the headlights adjusted professionally. Similarly, fog lights can also be adjusted like headlights. Position tape on a wall 25 feet in front of the vehicle and tape a horizontal line representing the height of the fog light centers, as well as another line four inches below. Remove the fasteners from the front portion of the inner fender splash shield to access the adjustment screws for the fog lights. Adjust the pattern on the wall so that the top of the fog light beam meets the lower line.
