How to remove and install Headlight Switch in Cadillac ElDorado and Fleetwood?

Disconnect the negative battery cable. For Deville and Fleetwood, remove the instrument panel trim plates as follows: On 1990-91 vehicles, remove the right and left sound insulators and snap out the upper steering column filler panel. Remove the lower steering column filler panel. Remove the screws from the tops of the trim plates and remove the left and right trim plates. Unscrew the screws at the bottom of the center trim plate and remove the trim plate. Remove the switch retaining screws and detach the electrical connector. Remove the knob and bezel from the switch. To install, the installation is the reverse of the removal procedure. Tighten the switch screws to 13 inch lbs.(1.5 Nm). For Eldorado and Seville 1990-91 models, disconnect the negative battery cable. Make sure all switches on the switch module are OFF. Remove the instrument cluster trim plate as follows: Remove the left side A/C vent. Remove the radio trim plate. Remove the retaining screws and the trim plate. Remove the 2 retaining screws and pull the switch module out of the electrical connectors in the instrument cluster. To install, the installation is the reverse of the removal procedure. For 1992-98 models, disconnect the negative battery cable. Firmly pull outward on the headlight switch knob to remove the switch module from the instrument panel. Detach the electrical connector and remove the switch. To install, the installation is the reverse of removal.

Genuine Cadillac Eldorado Headlight Switch

Headlamp Switch

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

21 Headlight Switches found

View related parts
Cadillac Eldorado Switch,Dimmer
Part Number: 26035244
$16.89 MSRP: $30.72
You Save: $13.83 (46%)
ADD TO CART
Product Specifications
- Other Name: SWITCH
- Replaces: 7841239, 07841239
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch Assembly, Headlamp
Part Number: 1995253
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch,Dimmer
Part Number: 26035567
Product Specifications
- Other Name: SWITCH
- Replaces: 26000904
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch,Turn Signal
Part Number: 19005028
Product Specifications
- Other Name: SWITCH, Turn Signal Lamp; Signal Switch, Turn Signal Hazard Switch
- Replaces: 1995971, 01995971
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-2002 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.6L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch Asm,Turn Signal
Part Number: 1995967
Product Specifications
- Other Name: SWITCH, Turn Signal Lamp; Signal Switch, Turn Signal Hazard Switch
- Replaces: 1997098
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1995 Cadillac Eldorado | ELDORADO | 8 Cyl 4.6L
View related parts
Cadillac Eldorado Switch,Wiper Pulse,Dimmer Pivot
Part Number: 7844704
Product Specifications
- Other Name: SWITCH, Headlamp Dimmer; Headlamp Dimmer Switch, Wiper Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch Assembly, Turn Signal
Part Number: 1997099
Product Specifications
- Other Name: SWITCH, Turn Signal Lamp
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1990-1991 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.5L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch, Steering Column Dimmer
Part Number: 26014807
Product Specifications
- Other Name: SWITCH, Headlamp Dimmer; Dimmer Switch, Headlamp Dimmer Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1997-2002 Cadillac Eldorado | ELDORADO | 8 Cyl 4.6L
View related parts
Cadillac Eldorado Switch,Dimmer
Part Number: 26035237
Product Specifications
- Other Name: SWITCH, Headlamp Dimmer; Dimmer Switch, Headlamp Dimmer Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1995 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.6L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch,Dimmer Pivot
Part Number: 7840274
Product Specifications
- Other Name: SWITCH, Headlamp Dimmer; Headlamp Dimmer Switch, Wiper Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch Asm
Part Number: 16504065
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch, Twilight Sentinal/Daytime Running Lamps Velet
Part Number: 16504066
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1982-1985 Cadillac Eldorado | BIARRITZ, COMMERCIAL CHASSIS, ELDORADO | 6 Cyl 4.1L, 8 Cyl 4.1L, 8 Cyl 5.7L Diesel
View related parts
Cadillac Eldorado Switch Assembly, Headlamp
Part Number: 3540700
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1997 Cadillac Eldorado | ELDORADO | 8 Cyl 4.6L
View related parts
Cadillac Eldorado Switch,Dimmer
Part Number: 26035238
Product Specifications
- Other Name: SWITCH, Headlamp Dimmer; Dimmer Switch, Headlamp Dimmer Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1993 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.6L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch Asm
Part Number: 1640025
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1986-1990 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.1L, 8 Cyl 4.5L
View related parts
Cadillac Eldorado Switch Assembly, Headlamp
Part Number: 3540699
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-2002 Cadillac Eldorado | ELDORADO | 8 Cyl 4.6L
View related parts
Cadillac Eldorado Switch Asm,Headlamp
Part Number: 1640024
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1986-1990 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.1L, 8 Cyl 4.5L
View related parts
Cadillac Eldorado Switch Asm
Part Number: 1646920
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1986-1991 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.1L, 8 Cyl 4.5L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch Assembly, Headlamp Auto Control
Part Number: 3538832
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1994 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.6L, 8 Cyl 4.9L
View related parts
Cadillac Eldorado Switch Assembly, Headlamp Auto Control
Part Number: 3538830
Product Specifications
- Other Name: SWITCH, Headlamp/Fog Lamp/Turn Signal; Headlamp Switch, Sentinel Switch
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1994 Cadillac Eldorado | COMMERCIAL CHASSIS, ELDORADO | 8 Cyl 4.6L, 8 Cyl 4.9L

| Page 1 of 2 |Next >

1-20 of 21 Results

Cadillac Eldorado Headlight Switch Parts Questions & Experts Answers

Switch Asm,Headlamp
1640024
Q: How to remove and install Headlight Switch in Cadillac ElDorado and Fleetwood?
A: Disconnect the negative battery cable. For Deville and Fleetwood, remove the instrument panel trim plates as follows: On 1990-91 vehicles, remove the right and left sound insulators and snap out the upper steering column filler panel. Remove the lower steering column filler panel. Remove the screws from the tops of the trim plates and remove the left and right trim plates. Unscrew the screws at the bottom of the center trim plate and remove the trim plate. Remove the switch retaining screws and detach the electrical connector. Remove the knob and bezel from the switch. To install, the installation is the reverse of the removal procedure. Tighten the switch screws to 13 inch lbs.(1.5 Nm). For Eldorado and Seville 1990-91 models, disconnect the negative battery cable. Make sure all switches on the switch module are OFF. Remove the instrument cluster trim plate as follows: Remove the left side A/C vent. Remove the radio trim plate. Remove the retaining screws and the trim plate. Remove the 2 retaining screws and pull the switch module out of the electrical connectors in the instrument cluster. To install, the installation is the reverse of the removal procedure. For 1992-98 models, disconnect the negative battery cable. Firmly pull outward on the headlight switch knob to remove the switch module from the instrument panel. Detach the electrical connector and remove the switch. To install, the installation is the reverse of removal.
